NVR 4-Channel DS-6904UDI | Hikvision
NVR 4-Channel DS-6904UDI | Hikvision

NVR 4-Channel DS-6904UDI | Hikvision

Product Features:

  • DS-6901UDI provides HDMI, VGA, and BNC output inter­faces.
  • DS-6904UDI, DS-6908UDI, DS-6910UDI, DS-6912UDI, DS-6916UDI provide HDMI (adapt­able to DVI-D) and BNC output inter­faces.
  • Up to 4K (3840 × 2160@30Hz) via HDMI output inter­faces (only for even inter­face).
  • Up to 16-ch decod­ing at 12 MP resol­u­tion (DS-6916UDI).
  • H.265+/H.265, H.264+/H.264, MPEG4 and MJPEG video compres­sion.
  • PS, RTP, TS, ES, HIK encap­su­la­tion formats.
  • Three encod­ing levels: baseline, main, and high-profile.
  • G.722, G711A, G726, G711U, MPEG2-L2, and AAC audio compres­sion.
  • Two decod­ing modes: active decod­ing and pass­ive decod­ing.
  • Remote video files’ decod­ing output.
  • Supports window open­ing and window roam­ing.
  • Supports multi-screen control with PC installed with RSC server.
  • Supports Wi-Fi module access to display the signal from an IOS/Android mobile phone or pad on the video wall.
  • 2-year offsite warranty from the manufacturing brand.
Category:

Experience the excellence of the NVR 4-Channel DS-6904UDI | Hikvision, offering comprehensive 4-channel recording with streamlined setup and high-definition clarity. Enhance your surveillance capabilities with a holistic solution for multi-camera setups and reliable, accurate recordings.

Comprehensive 4-Channel Recording

Elevate your surveillance capabilities with the NVR 4-Channel DS-6904UDI. This NVR 4-Channel DS-6904UDI is crafted to provide comprehensive 4-channel recording, offering a holistic solution for multi-camera setups. Ensure that every angle is covered with precision, enhancing your ability to monitor and analyze video feeds effectively.

Streamlined Setup and Integration

Experience a streamlined setup with the NVR 4-Channel DS-6904UDI, designed for hassle-free integration into your surveillance system. This NVR 4-Channel DS-6904UDI ensures a smooth flow of video data, making it an essential component of your infrastructure. Enjoy efficient network integration without compromising performance.

High-Definition Clarity

Despite handling multiple channels, the NVR 4-Channel DS-6904UDI delivers high-definition clarity in recording. Capture every detail with precision, ensuring that your surveillance system records crucial information accurately. Benefit from clear and reliable recordings for effective monitoring across all channels.

Product Specification:

Communication Type 2 Way Audio
Brand Hikvision
Model Name/Number DS-6904UDI
Number Of Channels 4
Input HDMI, DVI-I
Input Resolution WSXGA: 1680×1050/60Hz, WXGA: 1440 x 900/60Hz, WXGA: 1280×800/60Hz, 1366×768/60Hz, 1080p: 1920 x 1080
Output HDMI : 4-ch, BNC: 2-ch, 1 DB 15
Output Resolution HDMI: 4K: 3840 x 2160@30Hz ( for odd interface only) , 1080p: 1920 x 1080@50/60Hz, WSXGA: 1680×1050/
Decoding Resolution Up to 12MP (Support 24MP with 3 encoder tracks mode)
Decoding Channel 32-ch
Decoding Capability 24MP@30fps: 2-ch, 12MP@20fps:4-ch, 8MP@30fps: 8-ch, 5MP@30fps: 12-ch
Split Screen 1/2/4/6/8/9/12/16/25/36
Network Interface 2, 10/100/1000 Mbps self-adaptive management network interface 2, 10/100/1000 Mbps self-adaptive Eth
Serial Interface 1 RS-232 (RJ45), 1 RS-485
Two-Way Audio Out 1-ch, 3.5 mm connector (2.0 Vp-p, 1 K Ohm)
Two-Way Audio In 1-ch, 3.5 mm connector (2.0 Vp-p, 1 K Ohm)
Audio Output 4-ch, 1 DB 15
Working Temperature -10 DegreeC to +55 DegreeC (14 DegreeF to 131 DegreeF)
